Plots a median antibody response curve with a 95% credible interval ribbon, using MCMC samples from the posterior distribution. Optionally overlays observed data, applies logarithmic spacing on the y- and x-axes, and shows all individual sampled curves.

Usage

plot_predicted_curve(
  model,
  ids,
  antigen_iso,
  dataset = NULL,
  legend_obs = "Observed data",
  legend_median = "Median prediction",
  show_quantiles = TRUE,
  log_y = FALSE,
  log_x = FALSE,
  show_all_curves = FALSE,
  alpha_samples = 0.3,
  xlim = NULL,
  ylab = NULL,
  facet_by_id = length(ids) > 1,
  ncol = NULL
)

Arguments

model

An sr_model object (returned by run_mod()) containing samples from the posterior distribution of the model parameters.

ids

The participant IDs to plot; for example, "sees_npl_128".

antigen_iso

The antigen isotype to plot; for example, "HlyE_IgA" or "HlyE_IgG".

dataset

(Optional) A dplyr::tbl_df with observed antibody response data. Must contain:

  • timeindays

  • value

  • id

  • antigen_iso

legend_obs

Label for observed data in the legend.

legend_median

Label for the median prediction line.

show_quantiles

logical; if TRUE (default), plots the 2.5%, 50%, and 97.5% quantiles.

log_y

logical; if TRUE, applies a log10 transformation to the y-axis.

log_x

logical; if TRUE, applies a log10 transformation to the x-axis.

show_all_curves

logical; if TRUE, overlays all individual sampled curves.

alpha_samples

Numeric; transparency level for individual curves (default = 0.3).

xlim

(Optional) A numeric vector of length 2 providing custom x-axis limits.

ylab

(Optional) A string for the y-axis label. If NULL (default), the label is automatically set to "ELISA units" or "ELISA units (log scale)" based on the log_y argument.

facet_by_id

logical; if TRUE, facets the plot by 'id'. Defaults to TRUE when multiple IDs are provided.

ncol

integer; number of columns for faceting.

Value

A ggplot2::ggplot object displaying predicted antibody response curves with a median curve and a 95% credible interval band as default.

Examples

sees_model <- serodynamics::nepal_sees_jags_output
sees_data <- serodynamics::nepal_sees

# Plot (linear axes) with all individual curves + median ribbon
p1 <- plot_predicted_curve(
  model              = sees_model,
  dataset            = sees_data,
  id                 = "sees_npl_128",
  antigen_iso        = "HlyE_IgA",
  show_quantiles     = TRUE,
  log_y              = FALSE,
  log_x              = FALSE,
  show_all_curves    = TRUE
)
print(p1)


# Plot (log10 y-axis) with all individual curves + median ribbon
p2 <- plot_predicted_curve(
  model              = sees_model,
  dataset            = sees_data,
  id                 = "sees_npl_128",
  antigen_iso        = "HlyE_IgA",
  show_quantiles     = TRUE,
  log_y              = TRUE,
  log_x              = FALSE,
  show_all_curves    = TRUE
)
print(p2)


# Plot with custom x-axis limits (0-600 days)
p3 <- plot_predicted_curve(
  model              = sees_model,
  dataset            = sees_data,
  id                 = "sees_npl_128",
  antigen_iso        = "HlyE_IgA",
  show_quantiles     = TRUE,
  log_y              = FALSE,
  log_x              = FALSE,
  show_all_curves    = TRUE,
  xlim               = c(0, 600)
)
print(p3)


# Multi-ID, faceted plot (single antigen):
p4 <- plot_predicted_curve(
  model           = sees_model,
  dataset         = sees_data,
  id              = c("sees_npl_128", "sees_npl_131"),
  antigen_iso     = "HlyE_IgA",
  show_all_curves = TRUE,
  facet_by_id     = TRUE
)
print(p4)
